Blipbr Ultra Mini | GPS Asset Tracker

From: $189.00 excl. GST

GPS, WiFi sniffing and Cellular Tower Location means it locates both Indoor and Outdoor.

Latest technology Server-side location calculation extends battery life from 3- 5 times the regular Blipbr Mini!

Smallest GPS with Cellular connectivity for maximum coverage

Compact, Tough IP67 Water & Dust proof housing

Screw holes & cable-tie slots for easy mounting

Uses 3 AAA Lithium consumer batteries (not included)

Up to 10 year daily location or 3 years Intelligent Tracking*

Supplied with cellular SIM card installed and all data is included in the subscription pricing.

*Subject to volume of trips

Excludes Shipping & GST

SKU: MiniBlipbr-1 Category:
Blipbr Live view all assets on map

Locate

Easily keep an eye on all your stuff with the App or website.
Blipbr easily set a movement alert

Movement Alarm

Email and App alerts when your stuff moves!
Blipbr gps easyily set recovery mode for real-time tracking

Recovery Mode

Switch into Recovery Mode for real-time tracking.
Blipbe GPS quick history slider

Quick History

Keeps an accurate record of trip and location history.

Blipbr Mini Technical Specifications



BATTERIES

User-Replaceable Batteries 3 x AAA
Supported Battery Types Alkaline (works but not recommended for optimal battery life)
Lithium (LiFeS2) – Lithium recommended for best performance
*Please dispose of Lithium batteries in a safe and responsible manner
*Battery Life Once Daily location updates – up to 10 years
Movement-Based location updates – 3years
Hourly location updates – 2 years



LOCATION

Chipset Semtech LR1110
Constellation Concurrent GPS / BeiDou
Cloud-Based Solver Asset location is calculated in Digital Matter’s Location Engine
Tracking Sensitivity -134 dBm autonomous / -141 dBm aided
GNSS Assistance GNSS almanac data for greater sensitivity and position accuracy
Low Noise Amplifier GPS signals are filtered and boosted by a SAW filter and low-noise amplifier (LNA) allowing operation where other units fail
Cell Tower Location Cell tower fallback for positioning when there is no GNSS or WiFi signal
Wi-Fi Positioning Indoor asset location using Wi-Fi access point scanning (device does not connect to Wi-Fi)



POWER

Input Voltage 3-5.5V DC
Sleep Current <10uA*
*Average current in lowest power configuration.



MECHANICS / DESIGN

Dimensions Standard – 85 x 63 x 24 mm (3.35 x 2.48 x .94″)
Livestock Collar – 109 x 60 x 30 (4.29 x 2.36 x 1.18″)
Snap Housing (Smallest Size, not IP67 rated) – 75 x 45 x 25 mm (2.95 x 1.77 x 0.98″)
Weight Standard – 82 g (2.9 oz)
Housing Ultra-Rugged IP68 Housing. Non-branded housing for optional white-labeling.
IP Rating IP68 rated housing ensures device can withstand fine dust, high-pressure spray, submersion for 30 mins in 1m of water, and extreme temperatures
Installation Compact and concealable. Multiple installation options for covertly and easily securing the device to assets with screws, bolts, cable ties, rivets, and more. Stainless steel screws supplied. Collar housing available for securing device to livestock.
Operating Temperature -30°C to +60°C
For operation in extreme temperatures use Lithium Batteries
Cellular Antenna Internal
GPS Antenna Internal
Wi-Fi Antenna Internal
3-Axis Accelerometer 3-Axis Accelerometer to detect movement and high G-force events
Diagnostic LED Diagnostic LED indicates operation status
Flash Memory Store weeks of records if device is out of cellular coverage. Storage capacity for up to 5 days of continuous 30-second logging.
Speed and Heading Scanning technology used on the Blipbr Ultra Mini does not return speed and heading
On-Board Temperature The device reports internal temperature which provides an indication of ambient temperature but may not always be precise



SMARTS

Auto-APN Auto-APN allows the device to analyze the SIM card and select the correct APN details from a list that is pre-loaded in the device’s firmware
Battery Life Monitoring “Battery Low” and “Battery Critical” alert levels
Geofence Alerts The server can use device location to create geofences and alerts if an asset enters or leaves designated locations
Impact Detection Configure impact-detection alerts when G-forces are exceeded by a user-defined threshold
Intelligent Power Management Early registration abort and location scan throttling options
Periodic or Movement-Based Tracking Configure parameters to send updates based on set time intervals or when movement occurs. Adaptive tracking technology detects when the device is on the move and increases the update rate, providing detail when you need it while conserving battery when stationary.
Preventative Maintenance Set reminders based on distance traveled and run hours to reduce maintenance and repair costs
Run Hour Monitoring Capture run hours based on movement to understand and optimize asset utilization
Sleep Mode Stationary devices enter sleep mode until movement occurs to conserve battery life and optimize data usage
Theft Recovery Switch to Recovery Mode in the case of theft or loss to activate real-time tracking for asset retrieval
Tip Detection & Rotation Counting Axis angle reporting, tip detection and rotation counting



DEVICE MANAGEMENT

Flexible Configuration Configure device parameters such as position update rate, movement and accelerometer settings, and more to fit any tracking application
Device Management Platform Manage, monitor, configure, debug, update, and restart devices remotely from our cloud-based system.



SECURITY

Data Security Military-level AES-256 Encryption from device to OEM Server to protect the integrity and confidentiality of telematics data. Data forwarded to third-party systems is sent via HTTPS for end-to-end security.



WARRANTY

Manufacturer’s Warranty Two-year manufacturer’s warranty. Exclusions apply.



*Battery life estimates are influenced by several factors including temperature, installation and orientation of the device, the frequency of location updates, network coverage, sensor integrations, peripherals, accelerometer settings, and more.
